SUITABLE FOR SHORT-TIME VORTEX (TOUCH FUNCTION & CONTINUOUS SHAKE FUNCTION)
Product Features
- Sturdy metal die cast casing
- Short-time operation activated by pressing attachment/top
- Wide speed range, variable
- Suitable for continuous operation also with low self heating thanks to self ventilation of motor
- Different applications (3 interchageable attachment and 7 inserts (e.g. tubes, microtiter plate, conical flasks 250 ml etc.), please order separately)
- Attachments securely click onto appliance in any position
- Special strap (ensure easy handling of round/conical flasks
- Stable at high speeds thanks to special feet (sillicon base with ultra high vibration damping)
Technical Specification:
| Type of movement | Orbital |
| Shaking stroke/Orbit | 4 mm |
| Permissible shaking weight(incl. attachment) | 0.4 kg |
| Motor rating input | 58 W |
| Motor rating output | 10 W |
| Permissible ON time | 100% |
| Speed min (adjustable) | 500 rpm |
| Speed range | 0 – 2500 rpm |
| Speed display | none |
| Operating mode | continuous operation |
| Touch function | yes |
| Working with microtiter plates | yes |
| Number of microtiter plates | 1 |
| Dimensions (W x H x D) | 146 x 144 x 157 mm |
| Weight | 4 kg Approx |
| Permissible ambient temperature | 5 – 40 °C |
| Permissible relative Humidity | 80% |
| Protection class according to DIN EN 60529 | IP 21 |
| Power input | 60 W |
